Single Crystal Substrates
Created with Pixso. Epi Polish Ggg Gd3ga5o12 Single Crystal Substrates Low Optical Loss

Epi Polish Ggg Gd3ga5o12 Single Crystal Substrates Low Optical Loss

Brand Name: Crystro
Model Number: CR210427-01
MOQ: 1pc
Delivery Time: 3-4weeks
Payment Terms: T/T, Western Union, MoneyGram, Paypal
Detail Information
Place of Origin:
China
Certification:
SGS/ROHS
Item:
EPI Polish GGG Single Crystal Substrates
Orientation:
(111)
Lattice Constant:
12.497A
Density:
7.09g/cm3
Warranty::
1 Year
After-sales Service:
Video Technical Support, Online Support
Packing:
Vaccum Packing
Origin:
China
Packaging Details:
Transparent clean box
Supply Ability:
5000pcs per month
Highlight:

EPI Polish Single Crystal Substrates

,

Gd3Ga5O12 Single Crystal Substrates

,

EPI Polish GGG Single Crystal

Product Description

EPI Polish GGG Single Crystal Substrates



Gallium Gadolinium Garnet (Gd3Ga5O12 or GGG) single crystal subatrates is used as substrates for liquid epitaxy growth of YIG or BIG film.

GGG substrates is dedicated substrates for magneto optical film.



GGG has been successfully applied in the magnetic refrigeration industry in the temperature zone below 20 k for market HeII flow and helium-nitrogen liquefaction pre-stage refrigeration.

Crystro's GGG has low optical lossed(<0.1%/cm),high thermal conductivity(7.4W m-1K-1),High laser damage threshold(>1GW/cm2)




CRYSTRO offers:
Size Max 4inch dia
Thickness 0.5mm, 1.0mm
Polishing Single or double side
Orientation <111>,<100> ±2°
Edge orientation accuracy <2°
Edge Cutting custom
Roughness <0.5nm
Package thousand grade clean room,vaccum bags






Main Properties:



Chemical Formula Gd3Ga5O12
Lattic Parameter a=12.376Å
Growth Method Czochralski
Density 7.13g/cm3
Mohs Hardness 8
Melting Point 1725℃
Refractive Index 1.954 at 1064nm





document:



GGG SGGG NGG Crystal.pdf



Crystro has perfect automatic production machine, the current products are mainly concentrated in the YAG, TGG, TSAG,GGG ,LGS,Ce:GAGG ,Ce:YAG and Ce: LuYAG crystals.
We also established a crystal research center and developed different kinds of crystals. Keep providing technical support and training for new applications and product development staffs.
